Octave Horn Antennas、Multi Octave Horn Antennas
A-INFO社では、広帯域アプリケーションに最適なオクターブホーンアンテナを取り扱っております。
お客様のご希望に合わせてカスタマイズ可能です。仕様等お気軽にご相談ください。
オクターブホーンアンテナ
LBシリーズのオクターブホーンアンテナは直線偏波で、効率的かつ低コストな測定手段を提供します。
A-INFO社のオクターブホーンアンテナは1GHz～12GHzまでの周波数範囲をカバーできます。
これらのホーンアンテナは、EMI試験、方向探知、監視、アンテナ利得およびパターン測定、その他様々な用途に最適です。
マルチオクターブホーンアンテナ
LBシリーズのマルチオクターブホーンアンテナは直線偏波で、広帯域測定を効率的かつ低コストで実現します。
A-INFOのホーンアンテナは840MHz～55GHzまでの周波数範囲をカバーできます。
これらのホーンは、EMI試験、方向探知、監視、アンテナ利得およびパターン測定、その他の用途に最適です。
LBシリーズのホーンアンテナは、高利得、オクターブを超える帯域幅、低VSWR、小型軽量といった特長を備えています。試験報告書は参考用です。
製品ラインナップ
Octave Horn Antennas（LB-OHシリーズ）
Multi Octave Horn Antennas（LBシリーズ）
Octave Horn Antennas（LB-OHシリーズ）
| Model | Freq. Min （GHz） |
Freq. Max （GHz） |
Gain, Typ （dBi） |
Pol. | VSWR, Typ | Connector | Connector Gender | Datasheet |
|---|---|---|---|---|---|---|---|---|
| LB-OH-650-10-C-NF | 1 | 2 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-650-10-C-NFSPO | 1 | 2 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-650-10-C-SF | 1 | 2 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-650-10-C-SFSPO | 1 | 2 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-650-10-C-7/16F | 1 | 2 | 10 | Linear | 1.5:1 | 7/16 DIN | Female | Datasheet |
| LB-OH-650-10-C-7/16FSPO | 1 | 2 | 10 | Linear | 1.5:1 | 7/16 DIN | Female | Datasheet |
| LB-OH-650-15-C-NF | 1 | 2 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-650-15-C-NFSPO | 1 | 2 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-650-15-C-SF | 1 | 2 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-650-15-C-SFSPO | 1 | 2 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-650-15-C-7/16F | 1 | 2 | 15 | Linear | 1.5:1 | 7/16 DIN | Female | Datasheet |
| LB-OH-650-15-C-7/16FSPO | 1 | 2 | 15 | Linear | 1.5:1 | 7/16 DIN | Female | Datasheet |
| LB-OH-320-10-C-NF | 2 | 4 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-320-10-C-NFSPO | 2 | 4 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-320-10-C-SF | 2 | 4 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-320-10-C-SFSPO | 2 | 4 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-320-15-C-NF | 2 | 4 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-320-15-C-NFSPO | 2 | 4 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-320-15-C-SF | 2 | 4 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-320-15-C-SFSPO | 2 | 4 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-159-10-C-NF | 4 | 8 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-159-10-C-NFSPO | 4 | 8 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-159-10-C-SF | 4 | 8 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-159-10-C-SFSPO | 4 | 8 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-159-10-C-TF | 4 | 8 | 10 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-159-10-C-TFSPO | 4 | 8 | 10 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-159-10-C-7 | 4 | 8 | 10 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-159-10-C-7SPO | 4 | 8 | 10 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-159-10-C-3.5F | 4 | 8 | 10 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-159-10-C-3.5FSPO | 4 | 8 | 10 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-159-15-C-NF | 4 | 8 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-159-15-C-NFSPO | 4 | 8 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-159-15-C-SF | 4 | 8 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-159-15-C-SFSPO | 4 | 8 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-159-15-C-TF | 4 | 8 | 15 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-159-15-C-TFSPO | 4 | 8 | 15 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-159-15-C-7 | 4 | 8 | 15 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-159-15-C-7SPO | 4 | 8 | 15 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-159-15-C-3.5F | 4 | 8 | 15 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-159-15-C-3.5FSPO | 4 | 8 | 15 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-159-20-C-NF | 4 | 8 | 20 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-159-20-C-NFSPO | 4 | 8 | 20 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-159-20-C-SF | 4 | 8 | 20 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-159-20-C-SFSPO | 4 | 8 | 20 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-159-20-C-TF | 4 | 8 | 20 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-159-20-C-TFSPO | 4 | 8 | 20 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-159-20-C-7 | 4 | 8 | 20 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-159-20-C-7SPO | 4 | 8 | 20 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-159-20-C-3.5F | 4 | 8 | 20 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-159-20-C-3.5FSPO | 4 | 8 | 20 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-112-10-C-NF | 6 | 12 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-112-10-C-NFSPO | 6 | 12 | 10 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-112-10-C-SF | 6 | 12 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-112-10-C-SFSPO | 6 | 12 | 10 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-112-10-C-TF | 6 | 12 | 10 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-112-10-C-TFSPO | 6 | 12 | 10 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-112-10-C-7 | 6 | 12 | 10 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-112-10-C-7SPO | 6 | 12 | 10 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-112-10-C-3.5F | 6 | 12 | 10 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-112-10-C-3.5FSPO | 6 | 12 | 10 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-112-15-C-NF | 6 | 12 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-112-15-C-NFSPO | 6 | 12 | 15 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-112-15-C-SF | 6 | 12 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-112-15-C-SFSPO | 6 | 12 | 15 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-112-15-C-TF | 6 | 12 | 15 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-112-15-C-TFSPO | 6 | 12 | 15 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-112-15-C-7 | 6 | 12 | 15 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-112-15-C-7SPO | 6 | 12 | 15 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-112-15-C-3.5F | 6 | 12 | 15 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-112-15-C-3.5FSPO | 6 | 12 | 15 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-112-20-C-NF | 6 | 12 | 20 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-112-20-C-NFSPO | 6 | 12 | 20 | Linear | 1.5:1 | N Type | Female | Datasheet |
| LB-OH-112-20-C-SF | 6 | 12 | 20 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-112-20-C-SFSPO | 6 | 12 | 20 | Linear | 1.5:1 | SMA | Female | Datasheet |
| LB-OH-112-20-C-TF | 6 | 12 | 20 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-112-20-C-TFSPO | 6 | 12 | 20 | Linear | 1.5:1 | TNC | Female | Datasheet |
| LB-OH-112-20-C-7 | 6 | 12 | 20 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-112-20-C-7SPO | 6 | 12 | 20 | Linear | 1.5:1 | 7mm | N/A | Datasheet |
| LB-OH-112-20-C-3.5F | 6 | 12 | 20 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
| LB-OH-112-20-C-3.5FSPO | 6 | 12 | 20 | Linear | 1.5:1 | 3.5mm | Female | Datasheet |
Multi Octave Horn Antennas（LBシリーズ）
| Model | Freq. Min （GHz） |
Freq. Max （GHz） |
Gain, Typ （dBi） |
Pol. | VSWR, Typ | Flange | Connector | Connector Gender | Datasheet |
|---|---|---|---|---|---|---|---|---|---|
| LB-3582-10-C-HNF | 3.5 | 8.2 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-08420-10-A | 0.84 | 2 | 10 | Linear | 1.5:1 | FPWRD84D24 | No | N/A | Datasheet |
| LB-08420-10-ASPO | 0.84 | 2 | 10 | Linear | 1.5:1 | FPWRD84D24 | No | N/A | Datasheet |
| LB-08420-10-C-NF | 0.84 | 2 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-08420-10-C-NFSPO | 0.84 | 2 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-08420-10-C-SF | 0.84 | 2 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-08420-10-C-SFSPO | 0.84 | 2 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-08420-10-C-7/16F | 0.84 | 2 | 10 | Linear | 1.5:1 | No | 7/16 DIN | Female | Datasheet |
| LB-08420-10-C-7/16FSPO | 0.84 | 2 | 10 | Linear | 1.5:1 | No | 7/16 DIN | Female | Datasheet |
| LB-08420-15-A | 0.84 | 2 | 15 | Linear | 1.5:1 | FPWRD84D24 | No | N/A | Datasheet |
| LB-08420-15-ASPO | 0.84 | 2 | 15 | Linear | 1.5:1 | FPWRD84D24 | No | N/A | Datasheet |
| LB-08420-15-C-NF | 0.84 | 2 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-08420-15-C-NFSPO | 0.84 | 2 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-08420-15-C-SF | 0.84 | 2 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-08420-15-C-SFSPO | 0.84 | 2 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-08420-15-C-7/16F | 0.84 | 2 | 15 | Linear | 1.5:1 | No | 7/16 DIN | Female | Datasheet |
| LB-08420-15-C-7/16FSPO | 0.84 | 2 | 15 | Linear | 1.5:1 | No | 7/16 DIN | Female | Datasheet |
| LB-1536-10-A | 1.5 | 3.6 | 10 | Linear | 1.5:1 | FPWRD150D24 | No | N/A | Datasheet |
| LB-1536-10-ASPO | 1.5 | 3.6 | 10 | Linear | 1.5:1 | FPWRD150D24 | No | N/A | Datasheet |
| LB-1536-10-C-NF | 1.5 | 3.6 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-1536-10-C-NFSPO | 1.5 | 3.6 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-1536-10-C-SF | 1.5 | 3.6 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-1536-10-C-SFSPO | 1.5 | 3.6 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-1536-15-A | 1.5 | 3.6 | 15 | Linear | 1.25:1 | FPWRD150D24 | No | N/A | Datasheet |
| LB-1536-15-C-NF | 1.5 | 3.6 | 15 | Linear | 1.25:1 | No | N Type | Female | Datasheet |
| LB-2048-10-A | 2 | 4.8 | 10 | Linear | 1.5:1 | FPWRD200D24 | No | N/A | Datasheet |
| LB-2048-10-ASPO | 2 | 4.8 | 10 | Linear | 1.5:1 | FPWRD200D24 | No | N/A | Datasheet |
| LB-2048-10-C-NF | 2 | 4.8 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2048-10-C-NFSPO | 2 | 4.8 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2048-10-C-SF | 2 | 4.8 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2048-10-C-SFSPO | 2 | 4.8 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2048-15-A | 2 | 4.8 | 15 | Linear | 1.5:1 | FPWRD200D24 | No | N/A | Datasheet |
| LB-2048-15-ASPO | 2 | 4.8 | 15 | Linear | 1.5:1 | FPWRD200D24 | No | N/A | Datasheet |
| LB-2048-15-C-NF | 2 | 4.8 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2048-15-C-NFSPO | 2 | 4.8 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2048-15-C-SF | 2 | 4.8 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2048-15-C-SFSPO | 2 | 4.8 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2048-20-A | 2 | 4.8 | 20 | Linear | 1.5:1 | FPWRD200D24 | No | No | Datasheet |
| LB-2048-20-C-NF | 2 | 4.8 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2048-20-C-SF | 2 | 4.8 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2575-15-A | 2.5 | 7.5 | 15 | Linear | 1.5:1 | FPWRD250D30 | No | No | Datasheet |
| LB-2678-10-A | 2.6 | 7.8 | 10 | Linear | 1.5:1 | FPWRD250D30 | No | N/A | Datasheet |
| LB-2678-10-ASPO | 2.6 | 7.8 | 10 | Linear | 1.5:1 | FPWRD250D30 | No | N/A | Datasheet |
| LB-2678-10-C-NF | 2.6 | 7.8 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2678-10-C-NFSPO | 2.6 | 7.8 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2678-10-C-HNF | 2.6 | 7.8 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2678-10-C-SF | 2.6 | 7.8 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2678-10-C-SFSPO | 2.6 | 7.8 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2678-15-A | 2.6 | 7.8 | 15 | Linear | 1.5:1 | FPWRD250D30 | No | N/A | Datasheet |
| LB-2678-15-ASPO | 2.6 | 7.8 | 15 | Linear | 1.5:1 | FPWRD250D30 | No | N/A | Datasheet |
| LB-2678-15-C-NF | 2.6 | 7.8 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2678-15-C-NFSPO | 2.6 | 7.8 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2678-15-C-HNF | 2.6 | 7.8 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-2678-15-C-SF | 2.6 | 7.8 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2678-15-C-SFSPO | 2.6 | 7.8 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-2678-20-A | 2.6 | 7.8 | 20 | Linear | 1.50:1 | FPWRD250D30 | No | No | Datasheet |
| LB-2678-20-ASPO | 2.6 | 7.8 | 20 | Linear | 1.50:1 | FPWRD250D30 | No | No | Datasheet |
| LB-2678-20-C-NF | 2.6 | 7.8 | 20 | Linear | 1.50:1 | No | N Type | Female | Datasheet |
| LB-2678-20-C-HNF | 2.6 | 7.8 | 20 | Linear | 1.50:1 | No | N Type | Female | Datasheet |
| LB-2678-20-C-NFSPO | 2.6 | 7.8 | 20 | Linear | 1.50:1 | No | N Type | Female | Datasheet |
| LB-2678-20-C-SF | 2.6 | 7.8 | 20 | Linear | 1.50:1 | No | SMA | Female | Datasheet |
| LB-2678-20-C-SFSPO | 2.6 | 7.8 | 20 | Linear | 1.50:1 | No | SMA | Female | Datasheet |
| LB-3582-10-A | 3.5 | 8.2 | 10 | Linear | 1.5:1 | FPWRD350D24 | No | N/A | Datasheet |
| LB-3582-10-ASPO | 3.5 | 8.2 | 10 | Linear | 1.5:1 | FPWRD350D24 | No | N/A | Datasheet |
| LB-3582-10-C-NF | 3.5 | 8.2 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-10-C-NFSPO | 3.5 | 8.2 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-10-C-SF | 3.5 | 8.2 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-3582-10-C-SFSPO | 3.5 | 8.2 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-3582-10-C-ENF | 3.5 | 8.2 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-10-C-ESF | 3.5 | 8.2 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-3582-15-A | 3.5 | 8.2 | 15 | Linear | 1.5:1 | FPWRD350D24 | No | N/A | Datasheet |
| LB-3582-15-ASPO | 3.5 | 8.2 | 15 | Linear | 1.5:1 | FPWRD350D24 | No | N/A | Datasheet |
| LB-3582-15-C-NF | 3.5 | 8.2 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-15-C-NFSPO | 3.5 | 8.2 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-15-C-SF | 3.5 | 8.2 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-3582-15-C-SFSPO | 3.5 | 8.2 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-3582-15-C-ENF | 3.5 | 8.2 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-15-C-ESF | 3.5 | 8.2 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-3582-20-A | 3.5 | 8.2 | 20 | Linear | FPWRD350D24 | No | N/A | Datasheet | |
| LB-3582-20-C-NF | 3.5 | 8.2 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-20-C-SF | 3.5 | 8.2 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-3582-20-C-HNF | 3.5 | 8.2 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-20-C-ENF | 3.5 | 8.2 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-3582-20-C-ESF | 3.5 | 8.2 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-475110-10-A | 4.75 | 11 | 10 | Linear | 1.5:1 | FPWRD475D24 | No | N/A | Datasheet |
| LB-475110-10-ASPO | 4.75 | 11 | 10 | Linear | 1.5:1 | FPWRD475D24 | No | N/A | Datasheet |
| LB-475110-10-C-NF | 4.75 | 11 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-475110-10-C-NFSPO | 4.75 | 11 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-475110-10-C-SF | 4.75 | 11 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-475110-10-C-SFSPO | 4.75 | 11 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-475110-10-C-ENF | 4.75 | 11 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-475110-10-C-ESF | 4.75 | 11 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-475110-15-A | 4.75 | 11 | 15 | Linear | 1.5:1 | FPWRD475D24 | No | N/A | Datasheet |
| LB-475110-15-ASPO | 4.75 | 11 | 15 | Linear | 1.5:1 | FPWRD475D24 | No | N/A | Datasheet |
| LB-475110-15-C-NF | 4.75 | 11 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-475110-15-C-NFSPO | 4.75 | 11 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-475110-15-C-SF | 4.75 | 11 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-475110-15-C-SFSPO | 4.75 | 11 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-475110-15-C-ENF | 4.75 | 11 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-475110-15-C-ESF | 4.75 | 11 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-10-A | 5.8 | 16 | 10 | Linear | 1.5:1 | FPWRD580D28 | No | No | Datasheet |
| LB-58160-10-ASPO | 5.8 | 16 | 10 | Linear | 1.5:1 | FPWRD580D28 | No | N/A | Datasheet |
| LB-58160-10-C-NF | 5.8 | 16 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-10-C-NFSPO | 5.8 | 16 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-10-C-SF | 5.8 | 16 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-10-C-SFSPO | 5.8 | 16 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-10-C-ENF | 5.8 | 16 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-10-C-ESF | 5.8 | 16 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-15-A | 5.8 | 16 | 15 | Linear | 1.5:1 | FPWRD580D28 | No | Female | Datasheet |
| LB-58160-15-ASPO | 5.8 | 16 | 15 | Linear | 1.5:1 | FPWRD580D28 | No | N/A | Datasheet |
| LB-58160-15-C-NF | 5.8 | 16 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-15-C-NFSPO | 5.8 | 16 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-15-C-SF | 5.8 | 16 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-15-C-SFSPO | 5.8 | 16 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-15-C-ENF | 5.8 | 16 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-15-C-ESF | 5.8 | 16 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-20-A | 5.8 | 16 | 20 | Linear | 1.5:1 | FPWRD580D28 | No | N/A | Datasheet |
| LB-58160-20-ASPO | 5.8 | 16 | 20 | Linear | 1.5:1 | FPWRD580D28 | No | N/A | Datasheet |
| LB-58160-20-C-NF | 5.8 | 16 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-20-C-NFSPO | 5.8 | 16 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-20-C-SF | 5.8 | 16 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-20-C-SFSPO | 5.8 | 16 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-58160-20-C-ENF | 5.8 | 16 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-58160-20-C-ESF | 5.8 | 16 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-10-A | 6 | 18 | 10 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-10-ASPO | 6 | 18 | 10 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-10-C-NF | 6 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-10-C-NFSPO | 6 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-10-C-SF | 6 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-10-C-SFSPO | 6 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-10-C-HNF | 6 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-10-C-HNFSPO | 6 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-10-C-ENF | 6 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-10-C-ENM | 6 | 18 | 10 | Linear | 1.5:1 | No | N Type | Male | Datasheet |
| LB-60180-10-C-ESF | 6 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-15-A | 6 | 18 | 15 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-15-ASPO | 6 | 18 | 15 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-15-C-NF | 6 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-15-C-NFSPO | 6 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-15-C-SF | 6 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-15-C-SFSPO | 6 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-15-C-HNF | 6 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-15-C-ENF | 6 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-15-C-HNFSPO | 6 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-15-C-ENM | 6 | 18 | 15 | Linear | 1.5:1 | No | N Type | Male | Datasheet |
| LB-60180-15-C-ESF | 6 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-20-A | 6 | 18 | 20 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-20-ASPO | 6 | 18 | 20 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-20-C-NF | 6 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-20-C-NFSPO | 6 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-20-C-SF | 6 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-20-C-SFSPO | 6 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-20-C-HNF | 6 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-20-C-HNFSPO | 6 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-20-C-ENF | 6 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-20-C-ENM | 6 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-20-C-ESF | 6 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-23-A | 6 | 18 | 23 | Linear | 1.25:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-23-C-NF | 6 | 18 | 23 | Linear | 1.25:1 | No | N Type | Female | Datasheet |
| LB-60180-23-C-SF | 6 | 18 | 23 | Linear | 1.25:1 | No | SMA | Female | Datasheet |
| LB-60180-23-C-HNF | 6 | 18 | 23 | Linear | 1.25:1 | No | N Type | Female | Datasheet |
| LB-60180-23-C-ENF | 6 | 18 | 23 | Linear | 1.25:1 | No | N Type | Female | Datasheet |
| LB-60180-23-C-ENM | 6 | 18 | 23 | Linear | 1.25:1 | No | N Type | Male | Datasheet |
| LB-60180-23-C-ESF | 6 | 18 | 23 | Linear | 1.25:1 | No | SMA | Female | Datasheet |
| LB-60180-25-A | 6 | 18 | 25 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-25-ASPO | 6 | 18 | 25 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-60180-25-C-NF | 6 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-25-C-NFSPO | 6 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-25-C-SF | 6 | 18 | 25 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-25-C-SFSPO | 6 | 18 | 25 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-60180-25-C-HNF | 6 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-25-C-HNFSPO | 6 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-25-C-ENF | 6 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-60180-25-C-ENM | 6 | 18 | 25 | Linear | 1.5:1 | No | N Type | Male | Datasheet |
| LB-60180-25-C-ESF | 6 | 18 | 25 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-10-A | 6.5 | 18 | 10 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-10-ASPO | 6.5 | 18 | 10 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-10-C-NF | 6.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-10-C-NFSPO | 6.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-10-C-SF | 6.5 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-10-C-SFSPO | 6.5 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-10-C-HNF | 6.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-10-C-HNFSPO | 6.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-10-C-ENF | 6.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-10-C-ENM | 6.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Male | Datasheet |
| LB-65180-10-C-ESF | 6.5 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-15-A | 6.5 | 18 | 15 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-15-ASPO | 6.5 | 18 | 15 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-15-C-NF | 6.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-15-C-NFSPO | 6.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-15-C-SF | 6.5 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-15-C-SFSPO | 6.5 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-15-C-HNF | 6.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-15-C-HNFSPO | 6.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-15-C-ENF | 6.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-15-C-ENM | 6.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Male | Datasheet |
| LB-65180-15-C-ESF | 6.5 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-20-A | 6.5 | 18 | 20 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-20-ASPO | 6.5 | 18 | 20 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-20-C-NF | 6.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-20-C-NFSPO | 6.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-20-C-SF | 6.5 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-20-C-SFSPO | 6.5 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-20-C-HNF | 6.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-20-C-HNFSPO | 6.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-23-A | 6.5 | 18 | 23 | Linear | 1.25:1 | FPWRD650D28 | No | No | Datasheet |
| LB-65180-20-C-ENF | 6.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-20-C-ENM | 6.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Male | Datasheet |
| LB-65180-23-C-NF | 6.5 | 18 | 23 | Linear | 1.25:1 | No | N Type | Female | Datasheet |
| LB-65180-20-C-ESF | 6.5 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-23-C-SF | 6.5 | 18 | 23 | Linear | 1.25:1 | No | SMA | Female | Datasheet |
| LB-65180-23-C-HNF | 6.5 | 18 | 23 | Linear | 1.25:1 | No | N Type | Female | Datasheet |
| LB-65180-23-C-ENF | 6.5 | 18 | 23 | Linear | 1.25:1 | No | N Type | Female | Datasheet |
| LB-65180-23-C-ENM | 6.5 | 18 | 23 | Linear | 1.25:1 | No | N Type | Male | Datasheet |
| LB-65180-23-C-ESF | 6.5 | 18 | 23 | Linear | 1.25:1 | No | SMA | Female | Datasheet |
| LB-65180-25-A | 6.5 | 18 | 25 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-25-ASPO | 6.5 | 18 | 25 | Linear | 1.5:1 | FPWRD650D28 | No | N/A | Datasheet |
| LB-65180-25-C-NF | 6.5 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-25-C-NFSPO | 6.5 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-25-C-SF | 6.5 | 18 | 25 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-25-C-SFSPO | 6.5 | 18 | 25 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-65180-25-C-HNF | 6.5 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-25-C-HNFSPO | 6.5 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-25-C-ENF | 6.5 | 18 | 25 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-65180-25-C-ENM | 6.5 | 18 | 25 | Linear | 1.5:1 | No | N Type | Male | Datasheet |
| LB-65180-25-C-ESF | 6.5 | 18 | 25 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-70180-20-A | 7 | 18 | 20 | Linear | 1.5:1 | FPWRD750D24 | No | No | Datasheet |
| LB-75180-10-A | 7.5 | 18 | 10 | Linear | 1.5:1 | FPWRD750D24 | No | N/A | Datasheet |
| LB-75180-10-ASPO | 7.5 | 18 | 10 | Linear | 1.5:1 | FPWRD750D24 | No | N/A | Datasheet |
| LB-75180-10-C-SF | 7.5 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-10-C-SFSPO | 7.5 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-10-C-NF | 7.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-10-C-NFSPO | 7.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-10-C-HNF | 7.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-10-C-HNFSPO | 7.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-10-C-ESF | 7.5 | 18 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-10-C-ENF | 7.5 | 18 | 10 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-15-A | 7.5 | 18 | 15 | Linear | 1.5:1 | FPWRD750D24 | No | N/A | Datasheet |
| LB-75180-15-ASPO | 7.5 | 18 | 15 | Linear | 1.5:1 | FPWRD750D24 | No | N/A | Datasheet |
| LB-75180-15-C-SF | 7.5 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-15-C-SFSPO | 7.5 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-15-C-NF | 7.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-15-C-NFSPO | 7.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-15-C-HNF | 7.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-15-C-HNFSPO | 7.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-15-C-ESF | 7.5 | 18 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-15-C-ENF | 7.5 | 18 | 15 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-20-A | 7.5 | 18 | 20 | Linear | 1.5:1 | FPWRD750D24 | No | N/A | Datasheet |
| LB-75180-20-ASPO | 7.5 | 18 | 20 | Linear | 1.5:1 | FPWRD750D24 | No | N/A | Datasheet |
| LB-75180-20-C-SF | 7.5 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-20-C-SFSPO | 7.5 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-75180-20-C-NF | 7.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-20-C-NFSPO | 7.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-20-C-HNF | 7.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-20-C-HNFSPO | 7.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-20-C-ENF | 7.5 | 18 | 20 | Linear | 1.5:1 | No | N Type | Female | Datasheet |
| LB-75180-20-C-ESF | 7.5 | 18 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-110265-10-A | 11 | 26.5 | 10 | Linear | 1.5:1 | FPWRD110C24 | No | N/A | Datasheet |
| LB-110265-10-ASPO | 11 | 26.5 | 10 | Linear | 1.5:1 | FPWRD110C24 | No | N/A | Datasheet |
| LB-110265-10-C-SF | 11 | 26.5 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-110265-10-C-SFSPO | 11 | 26.5 | 10 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-110265-15-A | 11 | 26.5 | 15 | Linear | 1.5:1 | FPWRD110C24 | No | N/A | Datasheet |
| LB-110265-15-ASPO | 11 | 26.5 | 15 | Linear | 1.5:1 | FPWRD110C24 | No | N/A | Datasheet |
| LB-110265-15-C-SF | 11 | 26.5 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-110265-15-C-SFSPO | 11 | 26.5 | 15 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-110265-20-A | 11 | 26.5 | 20 | Linear | 1.5:1 | FPWRD110C24 | No | N/A | Datasheet |
| LB-110265-20-ASPO | 11 | 26.5 | 20 | Linear | 1.5:1 | FPWRD110C24 | No | N/A | Datasheet |
| LB-110265-20-C-SF | 11 | 26.5 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-110265-20-C-SFSPO | 11 | 26.5 | 20 | Linear | 1.5:1 | No | SMA | Female | Datasheet |
| LB-180400-10-A | 18 | 40 | 10 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-10-ASPO | 18 | 40 | 10 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-10-C-KF | 18 | 40 | 10 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-10-C-KM | 18 | 40 | 10 | Linear | 1.5:1 | No | 2.92mm（K） | Male | Datasheet |
| LB-180400-10-C-KFSPO | 18 | 40 | 10 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-10-C-2.4F | 18 | 40 | 10 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-10-C-2.4FSPO | 18 | 40 | 10 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-10-C-EKF | 18 | 40 | 10 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-10-C-E2.4F | 18 | 40 | 10 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-15-A | 18 | 40 | 15 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-15-ASPO | 18 | 40 | 15 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-15-C-KF | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-15-C-KFSPO | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-15-C-KM | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.92mm（K） | Male | Datasheet |
| LB-180400-15-C-2.4F | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-15-C-2.4FSPO | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-15-A_Al | 18 | 40 | 15 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-15-C-KF_Al | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-15-C-2.4F_Al | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-15-C-EKF | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-15-C-E2.4F | 18 | 40 | 15 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-20-A | 18 | 40 | 20 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-20-ASPO | 18 | 40 | 20 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-20-C-KF | 18 | 40 | 20 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-20-C-KFSPO | 18 | 40 | 20 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-20-C-KM | 18 | 40 | 20 | Linear | 1.5:1 | No | 2.92mm（K） | Male | Datasheet |
| LB-180400-20-C-EKF | 18 | 40 | 20 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-20-C-E2.4F | 18 | 40 | 20 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-20-C-2.4F | 18 | 40 | 20 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-20-C-2.4FSPO | 18 | 40 | 20 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-25-A | 18 | 40 | 25 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-25-ASPO | 18 | 40 | 25 | Linear | 1.5:1 | FPWRD180C24 | No | N/A | Datasheet |
| LB-180400-25-C-KF | 18 | 40 | 25 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-25-C-KM | 18 | 40 | 25 | Linear | 1.5:1 | No | 2.92mm（K） | Male | Datasheet |
| LB-180400-25-C-EKF | 18 | 40 | 25 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-25-C-E2.4F | 18 | 40 | 25 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-25-C-KFSPO | 18 | 40 | 25 | Linear | 1.5:1 | No | 2.92mm（K） | Female | Datasheet |
| LB-180400-25-C-2.4F | 18 | 40 | 25 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180400-25-C-2.4FSPO | 18 | 40 | 25 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-10-C-2.4F | 18 | 50 | 10 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-10-C-2.4FSPO | 18 | 50 | 10 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-10-C-E2.4F | 18 | 50 | 10 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-15-C-2.4F | 18 | 50 | 15 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-15-C-2.4FSPO | 18 | 50 | 15 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-15-C-E2.4F | 18 | 50 | 15 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-20-C-2.4F | 18 | 50 | 20 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-25-C-2.4F | 18 | 50 | 25 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-20-C-2.4FSPO | 18 | 50 | 20 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-20-C-E2.4F | 18 | 50 | 20 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-25-C-2.4FSPO | 18 | 50 | 25 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180500-25-C-E2.4F | 18 | 50 | 25 | Linear | 1.5:1 | No | 2.4mm | Female | Datasheet |
| LB-180550-10-C-1.85F | 18 | 55 | 10 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
| LB-180550-10-C-1.85FSPO | 18 | 55 | 10 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
| LB-180550-15-C-1.85F | 18 | 55 | 15 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
| LB-180550-15-C-1.85FSPO | 18 | 55 | 15 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
| LB-180550-20-C-1.85F | 18 | 55 | 20 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
| LB-180550-20-C-1.85FSPO | 18 | 55 | 20 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
| LB-180550-25-C-1.85F | 18 | 55 | 25 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
| LB-180550-25-C-1.85FSPO | 18 | 55 | 25 | Linear | 1.5:1 | No | 1.85mm（V） | Female | Datasheet |
